MAHITRI Technocrats Windshield Tag is designed for fast and reliable vehicle identi_cation. The passive UHF tag is designed to work on car windshield glass and suitable for wide section of Vehicles. It is designed to work for a wide range of vehicle identification applications such as toll road management, vehicle tracking, car washes, fleet management, parking permit, and access control. Using the alien 9654 RFID inlay, this product provides a read range of approximately 18+ feet. The inlay utilizes passive technology and is encapsulated between thin layers of polyester adding human readable printing to one side and a windshield-compatible adhesive to the other.
Our tags can be delivered with special production data and delivery forms integrate in customer issuing procedures.
Mahitri Technocrats windshield label is non-transferable and cannot be removed without being destroyed. A tamper-evident option with strategically placed slits in the label and adhesive layers is also available at no extra cost. The user memory is password protected and can hold encrypted user data.
Our tags can be delivered with special production data and delivery forms integrate in customer issuing procedures.
Mahitri Technocrats windshield label is non-transferable and cannot be removed without being destroyed. A tamper-evident option with strategically placed slits in the label and adhesive layers is also available at no extra cost. The user memory is password protected and can hold encrypted user data.
Data:
| Operating frequencies | EU: 865 – 868 MHz US: 902 – 928 MHz |
| Tamper proof | A tamper-evident option with strategically placed slits in the label |
| Reading range | EU: Up to 5 meters* (16 ft) and US: Up to 6 meters* (20 ft) |
| Writing range | EU: Up to 4 meters* (13 ft) and US: Up to 5 meters* (16 ft) |
| Dimensions | 4.5 x 1.5 in) thickness 0.022 in |
| Weight | 2.2 grams (0.078 oz) |
| Adhesive | Low surface energy, pressure-sensitive adhesive |
| Encapsulation material | .002" thick white polyester |
| Copy protection | SecureMarkID™ |
| Programmable data field | According to EPC Gen 2, ISO 18000-6C, 96 bits |
| Colour | White with print |
| Numbering Options | Serialized/ Unserialized numbers and barcode (Optional ) Code 128C |
| Environment | 25 °C (-13 °F) to +80 °C (+175 °F) Resists moderate solvents and caustics/acids |
| MAHITRI Technocrats Windshield Label offers a reliable and tamper evident solution for cost efficient traffic and vehicle management systems. | |
